PRIMINGSERVICE KIT
Priming is ALWAYS necessary after the tool has been dismantled and prior to operating. It may also be
necessary to restore the full stroke after considerable use, when the stroke may have been reduced and
fasteners are not now being fully placed by one operation of the trigger.
Oil Details
The recommended oil for priming is Hyspin® VG32 available in 0.51 or one gallon containers. Please see
safety data below.
Hyspin® VG 32 Oil Safety Data
First Aid
Priming Procedure
• Place tool on its side, Oil Plug 42 side up.
Pull back stroke set finger 88 and unscrew rear casing 86 by a maximum of 5 turns from the fully ‘IN’
position.
• With an Allen key, unscrew Oil Plug 42 and remove with Oil Seal Washer 43.
• Fill tool with priming oil rocking gently to expel air.
• Replace Oil Seal Washer 43 and Oil Plug 42 and tighten.
• You must now bleed the tool. This operation is to ensure air bubbles are eliminated from the oil circuit.
• Release the Trigger.
• Using an Allen key ropen Oil Plug 42.
• Top-up with priming oil to reset level. Replace Oil Seal Washer 43 and Oil Plug 42 and fully tighten.
• It is necessary to fit the appropriate nose equipment and adjust the tool stroke prior to operating the tool.
Item numbers in bold refer to General Assembly drawings and Parts List (pages 12-13).
For all servicing we recommend the use of the service kit (part number 74200-99990) supplied in its own
plastic case.
IMPORTANT : All operations should be carried out on a clean bench, with clean hands in a clean area.
Ensure that the oil is perfectly clean and free from air bubbles.
Care MUST be taken at all times, to ensure that no foreign matter enters the tool, or serious damage
may result. The tool must remain on its side throughout the priming sequence
SKIN: Wash thoroughly with soap and water as
soon as possible. Casual contact requires no
immediate attention. Short term contact requires
no immediate attention.
INGESTION: Seek medical attention immediately.
DO NOT induce vomiting.
EYES: Irrigate immediately with water for several
minutes. Although NOT a primary irritant, minor
irritation may occur following contact.
Fire: Flash point 232°C. Not classified as
flammable. Suitable extinguishing media: CO2, dry
powder, foam or water fog. DO NOT use water jets.
Environment: WASTE DISPOSAL: Through
authorised contractor to a licensed site. May
be incinerated. Used product may be sent for
reclamation.
SPILLAGE: Prevent entry into drains, sewers and
water courses. Soak up with absorbent material.
Handling: Wear eye protection, impervious gloves
(e.g. of PVC) and a plastic apron. Use in well
ventilated area.
Storage: No special precautions.
SERVICE KIT 74200-99990
Part Number Description QTY Part Number Description QTY
07900-00618 PUSHER 1 07900-00393 14mm/15mm SPANNER 1
07900-00619 GUIDE BUSH 1 07900-00409 12mm/13mm SPANNER 1
07900-00478 Ø 3mm PIN PUNCH 1 07900-00626 11mm SPANNER 1
07900-00624 Ø 4mm PIN PUNCH 1 07900-00469 2.5mm ALLEN KEY 1
07900-00157 INTERNAL CIRCLIP PLIERS 1 07900-00351 3mm ALLEN KEY 1
07900-00161 EXTERNAL CIRCLIP PLIERS 1 07900-00224 4mm ALLEN KEY 1
07900-00625 SOFT MALLET 1 07900-00225 5mm ALLEN KEY 1
07900-00623 25mm SOCKET 1 07900-00620 12mm ALLEN KEY 1
07900-00006 SPATULA 1 07900-00456 T BAR 1
07900-00434 32mm SPANNER 1 07992-00075 MOLYKOTE 55M
(100 gm TUBE)
1
07900-00621 28mm SPANNER 1 07900-00627 PLASTIC CASE 1
07900-00637 17mm SPANNER 1 07900-00632 17mm/19mm SPANNER 1
07900-00643 PUSHER KNOB 1
