13
6.2.3 Brightness/Intensity
Settings
50%
60%
70%
80%
100%
Button
6.2.3 Brightness/Intensity
With DIP switch dot-matrix 3, the brightness can be
changed by pressing the Dot-Matrix Button.
DIP switch dot-matrix 4 is reserved for later func-
tions and has no effect.
