Schaltbau CT1115/08 Series User Manual

User Manual, Power contactors, series CT1115/08 and CT1130/08
Rev. 2.2 Page 12/26
Order code
Example: CT1130/08 V 110ET-00 001
Number of poles
11 1-pole version
Nominal voltage
15 1.5 kV
30 3 kV
Conventional thermal current
08 800 A
Mounting position
H Horizontal (yellow lock bars)
V Vertical (red lock bars
Supply voltage
24 24 V
110 110 V
Supply voltage tolerance
E -30% … +25%
Coil suppression
T Suppressor diode
Auxiliary contacts
00 1x a1 (S870, refer to catalogue D70)
1x b0 (S870, refer to catalogue D70) M3 screw type terminals
2x NO/NC (S826, refer to catalogue D26)
01 1x a1 (S870, refer to catalogue D70)
1x b0 (S870, refer to catalogue D70) Flat tabs 6.3 x 0.8
2x NO/NC (S826, refer to catalogue D26)
02 4x NO/NC (S826, refer to catalogue D26) M3 screw type terminals
03 4x NO/NC (S826, refer to catalogue D26) Flat tabs 6.3 x 0.8
Special versions:
