CSV 409 A caravan charging system instruction manual
11
Issued: 20.02.2020
8050101 BA / EN
5.6 Closing d own th e system
Y ATTENTION!
Total discharge!
Damages the caravan battery:
F The caravan battery must be fully charged before closing down and
before restarting the system. (Vehicle with an 80 Ah battery must be
connected to the mains supply for at least 24 hours and a 160 Ah
battery for up to 36 hours.)
Y ATTENTION!
Permitted input voltage exceeded!
Will damage the consumers connected to the system:
F Never run a solar charger supplied by ’Schaudt’ without a battery
being connected to the system.
F Unplug the “+ solar-cell” connector on the solar charger first if the bat-
tery is going to be changed or removed.
Press the rocker switch (12 V main switch) so that it is briefly in the
“OFF” position.
The caravan battery must be fully charged before closing the system
down.
The caravan battery is then protected against total discharge. This applies
only if the battery is intact. Follow the instructions of the battery manufactu-
rer.
The caravan battery must be fully charged before closing the system
down.
Remove the clamps f rom the battery terminals.
Remove the “+ solar-cell” connector on the solar charger.
6 Technical details
6.1 Mechanical details
111 x 320 x 217 (H x W x D in mm), including attachment feet
2kg
PA (polyamide), gentian blue (RAL 5010)
6.2 Electrical details
230V AC 10%, 47 -- 63 Hz sinusoidal, protection class I
3.2 A
6-cell lead acid or lead gel batteries, 80 Ah and above
Without control and switch panel: 0 mA, plus consumption of refrigerator
control electronics;
With control and switch panel (e.g. LT310/LT409): approx. 2 -- 3 mA, plus
consumption of controller electronics of refrigerator
Closing down for up to
6 months
Closing down for more
than 6 months
Dimensions
Weight
Casing
Mains connection
Current consumption
Suitable batteries
Standby current from
Caravan battery
