10 Situation: 18.07.2005 SDT-0018-02EN
Instruction Manual Control and Switch Panel DT 201 B
The battery capacity can be displayed in ampere hours (Ah) and percent (%).
Switching between units
Press "OK" button.
The display of the battery capacity switches between the units ampere
hours (Ah) and percent (%).
The charging current of the living area battery is shown in amps (A).
Positive values indicate the charging current. Negative values indicate the
discharge current.
The battery display takes all types of battery charge into account in connec-
tion with the Electrobloc EBL 101:
P
Via the charger module of the 230 V mains
P
Via the cut-off relay of the alternator while driving
P
Via a solar charge regulator for the solar cells connected to the system
5.3.2 Checking the battery voltage
Battery button Press battery button twice briefly.
The voltages of living area battery and starter battery appear on the 2nd
page of the battery display.
Voltage in the living area battery
Voltage in the starter battery
The off-load voltage of the starter battery is only displayed if the engine is
switched off and if no consumers are using the starter battery.
W
The illumination of the display requires approx. 0.4 A. This illumination cur-
rent is added to the discharge current and displayed.
W
In order to register the entire power consumption, all consumers must be
connected to the Electrobloc. If consumers are connected directly to the
battery, the Schaudt system cannot register their power consumption. The
indication of current, battery capacity and charge request are not correct
in such an event.
W
If no button is pressed for 20 seconds, the system automatically switches
back to the basic display that is not illuminated. Entries that are not con-
firmed are not saved.
W
In mobile operation, the voltage of the starter battery is indicated slightly
too low, if the refrigerator is in use with 12 V. If the refrigerator is switched
off or operated using gas, the voltage display of the starter battery is cor-
rect. In stationary operation, the voltage of the starter battery is also dis-
played correctly.
