Instruction Manual EBL 101 D / EBL 101 C with OVP
13
Date: 29.04.2010
811.554 BA / EN
D Fault report
In the event of damage, please complete the fault report and send it toge-
ther with the faulty device to the manufacturer.
Device type: _______________________
Item no.: _______________________
Vehicle: Manufacturer: _______________________
Model: _______________________
Own installation? Yes - No -
Upgrade? Yes - No -
Following fault has occurred (please tick):
- Electrical consumers do not work -- which?
(please specify below)
- Switching on and off not possible
- Persistent fault
- Intermittent fault/loose contact
Other remarks:
E Techn ical details
230 V AC ± 10 %, 47 to 63 Hz sinusoidal, protection class I
1.9 A
Depending on the control and switch panel: approx. 5 -- 20 mA, plus con-
sumption of controller electronics of refrigerator
Measurement approx. 10 minutes after disconnection from the mains:
F
not connected to mains
F
12.6 V battery voltage
F
Battery isolation not enabled
F
Control and switch panel lighting off
F
12V main switch off
Loading of D+ output of the alternator by the Electroblock approx. 200 mA
without current consumption on D+ point
12V outputs A maximum of 90% of the nominal
current of the relevant fuse may be
drawn.
Mains connection
Current consumption
Standby current from
Living area battery
D+ loading
Current-carrying
capacity
