Operating Instruction Manual
Elektroblock EBL 263-5 Art no 911.056 page 3 / 10
Note: this operating instruction manual is intended for the customer and has to be supplied with the device
Schaudt GmbH, Elektrotechnik & Apparatebau, Daimlerstraße 5, D-88677 Markdorf, Tel +49 7544 9577-0, Fax +49 7544 9577-29, www.schaudt-gmbh.de 18.05.2004
2. Safety Information
* The electrical installation of the motor home has to be in accordance with current DIN-, VDE- and
ISO-regulations. Alterations will endanger the safety of persons and the vehicle. Due to the above
mentioned regulations and safety rules, alterations are, therefore, prohibited.
* The connection of the EBL to the mains supply has to be in accordance to national installation rules.
* The Elektroblock EBL 263-5 must not be modified.
* The connection of the Elektroblock should be carried out by qualified personnel only and must be
conform to specifications mentioned in this operating instruction manual:
see instruction manual section 4.2 'Installation'
section 5 'Electrical Installation'
and in enclosure schematic diagram of EBL 263-5
* In the following text special notice should be paid to the signs shown below:
Caution !
Electrical current hazard warning.
Caution !
General hazard warning.
3. Operating Instructions
3.1 Controls and Indicators
To turn on and off 12V supply of living-area
Actuate switch with 12V symbol ...
... up → 12V supply of living area is turned on. Green indicator lamp is on.
... down → 12V supply of living area is turned off. Green indicator lamp is off.
Note: The circuit 'automatic step' is not
switched by the 12V main switch.
Caution !
To avoid unnecessary discharge of the living-area battery the 12V supply should be
switched off when leaving the vehicle.
Inquiry of battery voltage
LED indication of battery voltage in three levels.
Actuate switch in direction of → Living-area battery condition is indicated.
Actuate switch in direction of → Starter battery condition is indicated.
