Schaudt EBL 263-5 - Additional Features and System Components; Waste Water Heater and Tank Level Inquiry; Battery-Type Selector Switch

Operating Instruction Manual
Elektroblock EBL 263-5 Art no 911.056 page 5 / 10
Note: this operating instruction manual is intended for the customer and has to be supplied with the device
Schaudt GmbH, Elektrotechnik & Apparatebau, Daimlerstraße 5, D-88677 Markdorf, Tel +49 7544 9577-0, Fax +49 7544 9577-29, www.schaudt-gmbh.de 18.05.2004
230V
To switch on and off the power supply of the waste water heater (optional)
Actuate switch with symbol ...
... up → The waste water heater may be switched on. Yellow indicator lamp is on.
... down → The waste water heater cannot be switched on. Yellow indicator lamp is off.
Note:
The waste water heater needs a considerable amount of power.
When used for long periods, the motor home should be on mains supply.
Caution !
Discharge of living-area battery with waste water heater switched on.
Inquiry of water tank filling levels
LED indication of water tank filling levels in three levels.
Actuate switch in direction of → Filling level of fresh water tank is shown
Actuate switch in direction of → Filling level of waste water tank is shown
LED with symbol is on → water tank full
LED with symbol is on → water tank approx half full
LED with symbol is on → water tank approx a quarter full
No LED indication → water tank empty
Note:
Inquiry of water tank filling levels is for temporary use only. The used method of measurement is
not suitable for continuous operation or long inquiries.
Caution !
Continuous operation or long inquiries will damage rod sensors or tank sensors.
Mains supply indicator
The yellow LED indicates that the EBL is connected to 230V
3.2 Additional Features
Battery-type selector switch The mains supply of the EBL has to be disconnected prior to actuating
the battery-type selector switch which is situated on the back of the EBL.
This switch has to be set according to the types of batteries used (lead-
acid or lead-gel) before the EBL is put into operation.
The switch ensures an optimum charge of the connected battery type.
To actuate use a thin tool like a ball point pen.
Caution !
An incorrectly set battery-type switch may damage the batteries and there may be an
explosion-hazard caused by detonating gas.
