Operating Instruction Manual
Elektroblock EBL 263-5 Art no 911.056 page 8 / 10
Note: this operating instruction manual is intended for the customer and has to be supplied with the device
Schaudt GmbH, Elektrotechnik & Apparatebau, Daimlerstraße 5, D-88677 Markdorf, Tel +49 7544 9577-0, Fax +49 7544 9577-29, www.schaudt-gmbh.de 18.05.2004
* For installation purposes, the mains plug or the mains supply of the vehicle must be disconnected.
Caution !
Danger of life due to electrical shock or danger of burning with a defective mains
cable, incorrect connection or service with mains supply on.
* Please note: all installation must be carried out with disconnected batteries.
* The electrical connection has to be in accordance to the following sequence:
1. 12V consumers, D+ (alternator) and water-tank connections
2. battery cables at EBL
3. battery cables at battery terminals
4. 230V mains connection
* Disconnection has to be executed vice versa.
5.1 230V Mains Supply
* The mains cable on the back of the device is strain-relieved. Its ends are push-on contacts 6.3 x 0,8.
* Mains supply has to be connected to a insulated earthing-contact junction box.
* The device must be used exclusively in vehicles equipped with an easily accessible cut-out, eg a
circuit breaker in the wardrobe.
5.2 Batteries and D+ (Alternator)
* The battery is connected by a 3-pole EURO terminal.
The alternator control signal D+, is connected to terminal 6 of the 6-pole plug-in screw terminal
('water tank 2, waste water').
* Cable size dimensions have to be in accordance with European norm EN 1648-1 or –2.
* Leads have to be fused according to their cross-sections.
Maximum allowed fuse ratings: Batteries D+ (Alternator)
30A 2A
* The fuses need to be installed close the battery terminals for short circuit protection of the leads
and alternator.
* The negative pole of the living-area battery has to be connected to the negative pole of the starter
battery externally.
Caution !
Danger of burning with incorrect connection and fusing.
* The EBL has to be used exclusively on 12V power systems with rechargeable 6-cell lead-acid or
lead-gel batteries.
Caution !
Unsuitable batteries will be damaged.
* Batteries have to be installed in sufficiently ventilated areas or must have integrated venting.
Please refer to installation instructions of the battery manufacturer.
Caution !
Exploding hazard by detonating gas with defective batteries, defective Elektroblock
or at too high battery temperature (> 30°C).
