811.550 BA / EN Edition: 21.08.2008 5
Instruction Manual Electrobloc EBL 101
5 Technical data
Mains connection 230 V AC ± 10 %, 47 to 63 Hz sinusoidal, protection class I
Suitable batteries 6-cell lead acid or lead gel batteries of at least 55 Ah
Closed circuit current from
living area battery
Depending on the control and switch panel: 15 - 20 mA
Current-carrying capacity 12 V outputs No more than 90 % of the rated current
of the appropriate fuse may be drawn,
see the block diagram.
Battery charging with
mains connection
Living area battery
Charging curve IUoU
Final charging voltage 14.3 V
Charging current 18 A
Voltage for float charge 13.8 V with automatic switching
Starter battery
Charging current Float charge max. 8 A
Battery charging via solar
charge regulator
Maximum charging current 14 A, fuse-protected by 15 A fuse
Depending on the solar charge regulator used, either only the living area bat-
tery is charged or the living area battery and the starter battery.
Battery charging while
travelling
Simultaneous charging of the starter battery and the living area battery by the
alternator
Batteries connected in parallel via a battery cut-off relay
Battery monitor The battery monitor of the control and switch panel controls the main switch
relays 1 and 2
Breaking voltage Approx. 10.5 V
Minimum battery voltage for switch-
ing on using 12 V main switch at the
control and switch panel
Approx. 11.0 V
