811.550 BA / EN Edition: 21.08.2008 9
Instruction Manual Electrobloc EBL 101
8 Shutting down the system
Disconnecting the living
area battery from the 12 V
power supply
Disconnect the living area battery from the 12 V power supply if you are not
going to use the motorhome for a lengthy period (e.g. during the winter).
❱ Switch off the 12 V main switch on the control and switch panel.
❱ Set the battery cut-off switch on the Electrobloc to "Batterie Aus" (battery
off).
❱ Remove the "+ Solar cell" plug on the solar charge regulator, if the battery
is going to be removed.
❱ Pull out the fuse for the AES refrigerator.
9 Changing the battery
Only use batteries of the same type and capacity and those installed by the
manufacturer.
You can change from lead acid to lead gel batteries.
You cannot change from lead gel to lead acid batteries. Ask your dealer for
advice.
▲ Before and after shutdown, the living area battery must be fully recharged
to avoid battery damage. For this purpose the vehicle must be connected
to mains supply for a minimum of 12 hours with an 80 Ah battery and
16 hours with a 160 Ah battery.
▲ Do not operate the Schaudt solar charge regulator without a battery. This
might damage the solar charge regulator or any connected consumers. If
the battery is going to be changed or removed, please first take off the pos-
itive lead "+ Solar Module" on the solar charge regulator.
▲ When the living area battery is separated from the Electrobloc by the bat-
tery cut-off switch, the frost protection valve of the heater system opens.
Water may be lost. For more information, see the instruction manual of the
heater system.
▲ The living area battery can also be charged using the internal charger
module, an auxiliary battery charging unit, the solar charge regulator and
the alternator when the battery cut-off switch is switched off.
▲ Batteries may only be changed by qualified personnel.
▲ Follow the instructions of the battery manufacturer.
▲ To disconnect the battery from the Electrobloc, all you need to do is set the
battery cut-off switch on the Electrobloc to "Batterie Aus" (battery off), see
section 8 "Shutting down the system".
▲ Charging unsuitable types of battery may irreparably damage them.
▲ Only use the Electrobloc for connecting the 12 V power supply to 6-cell
lead gel or lead acid batteries.
