811.550 BA / EN Edition: 21.08.2008 7
Instruction Manual Electrobloc EBL 101
Starting up the system ❱ Set the battery cut-off switch on the Electrobloc to "Batterie Ein" (battery
on).
❱ After switching on the battery cut-off switch or after changing batteries:
Switch on the 12 V main switch at the control and switch panel briefly to
put the consumers into service.
Shutting down the system ❱ Set the battery cut-off switch to "Batterie Aus" (battery off).
Battery selector switch
The switching option provided by the battery selector switch ensures optimum
charging of the two different types of battery, lead acid and lead gel. The
switch must be set to the correct battery type: lead acid or lead gel.
Use a thin object (e.g. a ballpoint pen cartridge) to move the battery selector
switch.
❱ Set lead gel battery: Set the battery selector switch to "Blei-Gel" (lead gel).
❱ Set the lead acid battery: Set the battery selector switch to "Blei-Säure"
(lead acid).
12 V main switch (on the
control and switch panel)
The 12 V main switch on the control and switch panel switches all consumers
and the panel on and off.
Exceptions:
●
Heater
●
Floor light/step
●
Frost protection valve
●
AES/compressor refrigerator
●
Spare 4
For more information, see the instruction manual of the control and switch
panel.
▲ When the living area battery is separated from the Electrobloc by the bat-
tery cut-off switch, the frost protection valve of the heater system opens.
Water may be lost. For more information, see the instruction manual of the
heater system.
▲ There is a danger of explosion due to the formation of detonating gas if
the battery selector switch is incorrectly set.
▲ An incorrectly set battery selector switch damages the living area battery.
▲ Disconnect the Electrobloc from the mains before adjusting the battery
selector switch.
