Scheiber MB-BOX - Installation Instructions

L’innovation française depuis 1965
P. 5
L’innovation française depuis 1965
FIXING: 2 SCREWS 2.9X19MM
MOUNTING DISTANCE: 137mm
95
150
Front view
Prole view
Back view
25
ETHERNET
USB
-
C
ANTENNE
CAN 1
CAN 0
POWER SUPPLY
I/O
USB
-
C
Installation instructions
• This device must be placed in a place protecting it from any risk of water splashing. Install in a ventilated location
• Do not install on supports that are sensitive to heat, such as carpet or PVC ooring, etc.
• The product must be installed away from heat and humidity
!
WARNING: Connection/disconnection with power on
Do not perform connection or disconnection with power on.
