Scheiber WIFI SERVER User Manual

4
POWER SUPPLY MANAGEMENT
Power modes:
On, Standby, Hibernate
Standby exit events (wake-up):
RTC and wake-up by Scheiber bus
Li-ion battery/monitor charger:
Yes
CLOCK
Real-Time Clock:
Yes
PERIPHERALS
CAN bus:
Up to 2 channels, CAN bus 2.0B, 250 kbit/s bit rate
Scheiber Multibloc V8 protocol
SD card:
Yes
High-speed USB 2.0:
Up to 1 high-speed USB 2.0 (with PHY)
Up to 1 USB 2.0 OTG port (with PHY)
Ethernet:
Up to 2 Ethernet connectors
Physical layer: 10/100Base-T
Data rate: 10/100 Mbps, automatic detection
Duplex mode: Full or half-duplex, automatic detection
WIFI
Standard:
802.11 a/b/g/n
Antenna connector:
Yes
Frequency bands:
2.412 - 2.484 GHz
4.900 - 5.850 GHz
Data rate:
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: 15, 30, 45, 60, 90, 120, 135, 150 Mbps
(HT40, MCS 0-7)
Modulation:
DBPSK, DQPSK, CCK, BPSK, QPSK, 16-QAM, 64-QAM
Transmission power (±2 dBm):
802.11b: 10.5 dBm typical
Security:
WEP, WPA-PSK/WPA2-Personal, WPA/WPA2 Enterprise, 802.11i
ENERGY CONSUMPTION
Wi-Fi 2.4 GHz Transmission, CPU 454
MHz, 50%, UART active:
260 mA @ 12 V
Wi-Fi 2.4 GHz Reception,
CPU Idle (Auto Slow):
160 mA @ 12 V
WiFi
CPU on Standby (IRQ):
25 mA @ 12 V
WiFi on Standby (Host off),
CPU Hibernating (RTC):
0.6 mA @ 12 V
ENVIRONMENT
Operating temperature:
-40°C to + 85°C (-40°F to + 185°F)
Storage temperature:
-40°C to + 85°C (-40°F to + 185°F)
Relative humidity:
5% to 90% (without condensation)
