Scheiber WIFI SERVER User Manual

3
ACCESSORIES/ASSOCIATED PARTS
ACCESSORIES TO BE ORDERED SEPARATELY:
 120 Ω CAN bus termination
TECHNICAL CHARACTERISTICS
WIFI SERVER TECHNICAL CHARACTERISTICS
PART NUMBER:
36.159446.00
PERIPHERALS:
2 Ethernet/WiFi ports
1 SD port
1 USB port (option)
1 Micro USB port
1 connector for temperature sensor
2 independent CAN networks (4 connectors)
JST CONNECTOR:
For management of an outside temperature sensor
CAN BUS:
4 x 6-way Micro-Fit connectors (2 separate networks)
WIFI:
802.11 A/B/G/N
USB:
Connection with 3G modem
SECURITY:
WEP, WPA-PSK/WPA2-Personal, WPA/WPA2 Enterprise, 802.11i
EXTERNAL POWER SUPPLY:
8/30 VDC
BATTERY POWER SUPPLY:
4.2 V Li-ion battery
FASTENER CENTRE-TO-CENTRE DISTANCE:
128 x 87 mm
DIMENSIONS (L x W x H):
150 x 95 x 25 mm
WEIGHT:
0.21 kg
WIFI SERVER HARDWARE SPECIFICATIONS
PROCESSOR
Processor models:
Freescale® i.MX28x
Speed grade:
Up to 454 MHz
Core type:
ARM926EJ-S
Cache memory:
16k I-Cache, 32k D-Cache
Internal RAM:
128 kB SRAM
Internal RAM (OCOTP):
1,280 bits
POWER
Flash:
128 Mb NAND flash
RAM:
128 Mb DDR2
MEMORY
(X1 - X2) CAN bus A (6-way):
8 - 12 VDC
(X3 - X4) CAN bus B (6-way):
8 - 12 VDC
(J2) Battery (2-way):
4.2 V Li-ion battery
(J3) External power supply (4-way):
8 - 30 VDC
