Installing the paper lter bag (14) (g. 3, 8)
It is recommended to use an additional paper lter
bag (14) when vacuuming ne, dry dirt. Slide the
paper lter bag (14) over the suction opening in the
stainless steel container (7). The paper lter bag (14)
is only suitable for dry vacuuming. The paper lter
bag (14) makes it easier to dispose of the dust col-
lected.
Installing the suction hose (12) (g. 3, 9, 10)
Connect the suction hose (12) to the corresponding
port, depending on the desired use, on the wet and
dry vacuum.
Vacuuming:
Connect the suction hose (12) to the suction hose
port (8).
Blowing:
Connect the suction hose (12) to the suction hose
port (10).
Installing the plastic extension tubes (17), suction
hose (12) and oor nozzle (16) (g. 3, 11)
Connect the assembled plastic extension tubes (17)
with the bent end of the suction hose (12).
Fit the oor nozzle (16) to the other end of the as-
sembled plastic extension tubes. The bent end of the
suction hose (12) can be used as a joint nozzle.
8. Operation
m WARNING!
Switch the device off if liquid or foam emerges with
the exhaust air during wet vacuuming.
Switching on/off (g. 12)
The on/off switch (9) has two settings
• Switch setting 0: Off
• Switch setting I: On
Press the on/off switch (9) to switch on. Switch set-
ting I: On
Press the on/off switch (9) again to switch the device
off. Switch setting 0: Off
Dry vacuuming (g. 3, 7, 8)
Use the folded lter (15) for dry vacuuming. The pa-
per lter bag (14) can be used in addition. This en-
sures that the folded lter (15) remains free of dust for
longer and maintains the vacuum power for longer.
In addition, the disposal of the dust is also easier.
Always ensure that the lters are correctly tted.
Wet vacuuming (g. 3, 6)
Use the foam lter (13) for wet vacuuming. Ensure
that the foam lter (13) is correctly tted.
If the stainless steel container (7) is full, the safety
oat valve (11) closes the suction port and suction op-
eration is interrupted.
6. Technical Data
Mains voltage 220-240 V~ 50/60 Hz
Power 1200 W
Water tank capacity 15 L
Suction performance 16-18 Kpa
Protection category IPX4
Protection class II
7. Installation
m IMPORTANT!
Prior to use, ensure that the device has been cor-
rectly and fully assembled.
Unpacking (g. 1, 2, 3)
• Release the locking hooks (4) and remove the ma-
chine head (2). The accessories are located inside
the stainless steel container (7). Only the plastic
extension tubes (3x) (17) are located outside the
stainless steel container, in the packaging. Remove
all of the accessories from the stainless steel con-
tainer (7).
Installing the castors (5) (g. 4)
• Turn the stainless steel container (7) upside-down
(the machine head (2) must be removed).
• Press the four castors (5) into the holes in the wheel
mounting base (6).
Installing the machine head (2) and the handle (1)
(g. 5)
1 Place the machine head (2) on the stainless steel
container (7). Secure the machine head (2) with
the locking hooks (4). When installing the machine
head (2), ensure that the locking hooks (4) latch into
place correctly.
2 Place the handle (1) on the machine head (2) and
fasten it with two screws (18) with a screwdriver
(not included in the delivery).
Installing the foam lter (g. 3, 6)
Never use the device without lter! Always ensure
that the lters are correctly tted!
Installing the foam lter (13): For wet vacuuming, slide
the foam lter (13) provided over the lter basket with
safety oat valve (11).
Installing the folded lter (15) (g. 3, 7)
For dry vacuuming, slide the folded lter (15) provided
over the lter basket with safety oat valve (11). The
folded lter (15) is only suitable for dry vacuuming!
