Scheppach DC500 Original Instruction Manual

www.scheppach.com
22
|
GB
Rated input 550 W
Motor speed 2900 min
-1
Technical changes reserved!
Noise and vibration
m Warning: Noise can have serious e󰀨ects on your
health. If the machine noise exceeds 85 dB (A), please
wear suitable hearing protection.
7. Unpacking
m ATTENTION!
The device and the packaging material are not
children’s toys! Do not let children play with plas-
tic bags, lms or small parts! There is a danger of
choking or su󰀨ocating!
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the device and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating instructions before using for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
• When ordering please provide our article number as
well as type and year of manufacture for your equip-
ment.
8. Assembly / Before commissioning
m ATTENTION!
Always make sure the device is fully assembled
before commissioning!
8.1 Machine stand assembly (g. 3 - 6)
• Secure the two wheels using a washer (15) and a
split pin (16) each (g. 3).
• Secure the right-hand side panel (5a) and the left-
hand side panel (5b) using two llister head screws
(18) and two hexagon nuts (19) (g. 4).
m WARNING! This power tool generates an electro-
magnetic eld during operation. This eld can impair
active or passive medical implants under certain con-
ditions. In order to prevent the risk of serious or deadly
injuries, we recommend that persons with medical im-
plants consult with their physician and the manufactur-
er of the medical implant prior to operating the power
tool.
Residual risks
The machine has been built according to the state-
of-the-art and the recognised technical safety re-
quirements. However, individual residual risks can
arise during operation.
• Risk to health from wood dust or wood chippings.
Wearing personal protective equipment such as pro-
tective goggles and dust masks is mandatory.
• Dust inhalation may occur when closing and chang-
ing the dust collection bag. A failure to observe the
disposal notes in the operating instructions (e.g. re-
garding the use of dust masks P2) may result in dust
inhalation.
• Risk to health due to noise. The permissible noise
level is exceeded during operations. It is essential
that personal protective equipment, such as hearing
protection, is worn.
• Hazard due to electrical power with the use of im-
proper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the “Safety in-
structions” and the “Proper use” are observed along
with the whole of the operating instructions.
Keep these safety instructions in a safe place.
6. Technical data
Suction port, connection Ø 100 mm
Hose length 2000 mm
Air power 1150 m³/h
Pressure di󰀨erence 900 Pa
Filter surface approx. 1 m²
Container volume approx. 75 l
Weight 14 kg
Electric motor 230 V~ / 50Hz

Scheppach DC500 Specifications

General

Cleaning type	Dry
Product color	White
Housing material	-
Input power	550 W
Capacity	75 L
Hose length	2 m
Hose diameter	100 mm
Airflow (high speed)	1150 m³/h

Weight and Dimensions

Depth	750 mm
Width	460 mm
Height	420 mm
Weight	16000 g
