75
Assembly
Fig.3-5
For technical packaging reasons, your machine is not as-
sembled fully.
1 Take the machine out of the packing and place it
laterally on the floor very carefully.
2 Introduce the legs (3) into the base frame and lock
them with butterfly nuts (A) (Fig. 3).
3 Set the machine on its legs.
4 Install the handle with 2 cross-recess screws (B) on
the motor casing (Fig. 4).
Note: The handle can also be mounted on the opposite side
5 Place the tub (4) in the base frame (2).
6 Place the cooling water pump (14) in the tub (4)
7 Fill water till the pump (14) is filled completely with
water (Fig.4).
8 Pull out the pin of the transport lock (13) (Fig.5).
Start-up
On/Off switch (Fig. 4)
To activate the machine, press the „I“ of the On/Off
switch (17).
Before starting the cutting operation, you must wait for
the cutting disc to reach its max. speed and for the coo-
ling water pump (14) to pump water to the cutting disc.
To deactivate the machine, press the „0“ of the switch
(16). (Fig. 4).
Operation
90° cutting Fig.6-7
1 Loosen the wing bolt (C)
2 Set angled stop (6) to 90° and tighten the wing bolt
(C) again.
3 Tighten the wing bolt (D) to fix the angled stop (6).
(Fig.6)
4 Push the machine head (1) towards the rear by the
handle (11).
5 Place the tile on the stop rail (7) at the angled stop
(6).
6 Switch the tile-cutting machine on. (Fig.7)
Caution: Wait for the cooling water to reach the cutting
disc (10).
7 Pull the machine head (1) slowly and uniformly by the
handle (11) in the forward direction through the tile.
8 Switch the tile-cutter off again after reaching the end.
