www.scheppach.com
18
|
GB
Such damaged electrical connection cables must
not be used and are life-threatening due to insu-
lation damage.
Check the electrical connection cables for damage
regularly. Ensure that the connection cables are dis-
connected from electrical power when checking for
damage.
Electrical connection cables must comply with the ap-
plicable VDE and DIN provisions. Only use connection
cables with designation H07-RN.
The printing of the type designation on the cable is
mandatory.
AC motor
• The mains voltage must be 230 volts/50 Hz.
• Extension cables must have a minimum cross sec-
tion of 1.0 square millimetres.
• The mains connection is protected with a 16 A slow-
blow fuse.
Please provide the following information in the event
of any enquiries:
• Engine manufacturer
• Type of current for the motor
• Machine data - type plate
• Data of switch type plate
When returning the motor always send in the complete
drive unit with switches.
12. Disposal and recycling
Notes for packaging
The packaging materials are recy-
clable. Please dispose of packag-
ing in an environmentally friendly
manner.
Wearing parts*: carbon brushes, lter bag, sawdust
bag, extraction hose, nozzle attachments; V-belt
* may not be included in the scope of supply!
Spare parts and accessories can be obtained from our
service centre. To do this, scan the QR code on the
cover page.
Special accessories
Filter bag art. no. 3906301013
Returnable sawdust bag 20 pcs. art. no. 75001500
10. Storage
Store the device and its accessories in a dark, dry and
frost-free place that is inaccessible to children. The op-
timum storage temperature lies between 5 and 30 ˚C.
Store the electric tool in its original packaging.
11. Electrical connection
Connections and repair work on the electrical equip-
ment may only be carried out by electricians.
The electrical motor installed is connected and ready
for operation. The connection complies with the appli-
cable VDE and DIN provisions.
The customer‘s mains connection as well as the ex-
tension cable used must also comply with these reg-
ulations.
Important information
Damaged electrical connection cables
If the power cable is damaged, it must be replaced by
the manufacturer or their service department or a simi-
lar qualied person in order to avoid hazards.
The insulation on electrical connection cables is often
damaged.
Causes are:
• Pressure points, where connection cables are
passed through windows or doors.
• Kinks where the connection cable has been improp-
erly fastened or routed.
• Places where the connection cables have been cut
due to being driven over.
• Insulation damage due to being ripped out of the wall
outlet.
• Cracks due to the insulation ageing.
