Electrical Connection
m WARNING! Electric shock! There is a risk of
an injury caused by electric shock!
Defective cable or plug may cause electric shock.
Avoid body contact with earth parts to protect your-
self from electric shocks.
m Operation is only allowed with a safety switch
against stray current (RCD max. stray current of
30mA).
Insert the plug of the electrical cable in a socket of
suitable shape, voltage and frequency complying
with current regulations.
Do not pull the service cable to pull the plug out of
socket.
The electric motor is connected in a ready-to-
operate state. The connection corresponds to
the relevant VDE and DIN regulations.
The mains connection at the customer’s work
place and the extension cable used must cor-
respond to these regulations.
Important information
In the event of an overloading the motor will switch
itself off. After a cool-down period (time varies) the
motor can be switched back on again.
Faulty electrical connecting leads
Insulation damage often occurs at electrical con-
necting leads.
Causes include:
• Pressure marks caused when connecting leads
are run through windows or the cracks of doors.
• Folds caused by the improper attachment of run-
ning of the connecting leads.
• Cutsresulting from the crossing of the connect-
ing lead.
• Insulation damages caused by the ripping out of
the connecting lead from the wall socket.
• Cracks due to the ageing of the insulation.
Faulty electrical connecting leads such as these
may not be used and are highly dangerous due to
the insulation damage.
Check electrical connecting leads regularly for
damage. Ensure that the connecting lead is not at-
tached to the mains supply when you are checking
it.
Electrical connecting leads must correspond to the
relevant VDE and DIN regulations. Only use con-
necting leads with the code H05VV-F.
The type designation must be printed on the con-
necting lead by regulation.
AC motor
• The supply voltage must be 230 volt ~ / 50 Hz.
• Extension leads up to 25 m in length must have
a cross-section of 1.5 mm², > 25 m length / 2,5
mm².
Connections and repairs of electrical equipment
may only be performed by a qualied electrician.
Please give the following information if you have
any enquiries:
• Kind of current
• Machine type label data
• Data on the main label
6. Disposal and recycling
The equipment is supplied in packaging to prevent it
from being damaged in transit. The raw materials in this
packaging can be reused or recycled. The equipment
and its accessories are made of various types of mate-
rial, such as metal and plastic. Never place defective
equipment in your household refuse. The equipment
should be taken to a suitable collection center for proper
disposal. If you do not know the whereabouts of such a
collection point, you should ask in your local council of
ces.
The determination of the causes of available disturbanc-
es and their removal require constantly increased atten-
tion and caution. Pull power supply plugs off in advance!
In the following are specied some of the most frequent
disturbances and their causes. For further disturbances,
please contact your dealer.
