Cutting data pole saw
Bar length 300 mm
Cutting length 260 mm
Cutter bar Type AL10-39-507P
Saw chain division 3/8"
Chain type 3/8.050-39
Chain link thickness 1,27 mm
Oil tank capacity 140 cm³
Speed Pole saw min. 10000 min¹
Power unit
Displacement 42,7 cm³
Max. engine output 1,25 kW
Idle speed 3200
±300
min¹
Fuel tank capacity 1200 cm³
Engine type
2-stroke engine,
air-cooled
Weight grass trimmer 8,5 kg
Weight brush cutter 8,5 kg
Weight pole saw 7,5 kg
Weight hedge trimmer 7,9 kg
Subject to technical changes!
Information concerning noise emission measured ac-
cording to relevant standards:
Sound pressure L
pA
= 93 dB
Sound power L
WA
= 113 dB
Uncertainty K
PA
= 3 dB
Wear ear-mus.
The impact of noise can cause damage to hearing.
Vibrations:
Grass trimmer: A
hveq
= Front 6,67 m/s
2
Rear 6,48 m/s
2
Brush cutter: A
hveq
= Front 7,15 m/s
2
Rear 6,83 m/s
2
Reduce noise generation and vibration to a minimum!
• Use only equipment that is in perfect condition.
• Maintain and clean the equipment regularly.
• Adopt your way of working to the equipment.
• Do not overload the equipment.
• Have the equipment checked if necessary.
• Switch o the equipment when not in use.
• Wear gloves.
In these operating instructions we have marked
the places that have to do with your safety with
this sign: m
7. Before starting the equipment
Each time before use, check the following:
• That there are no leaks in the fuel system.
• That the equipment is in perfect condition and that
the safety devices and cutting devices are com-
plete.
• That all screws are securely fastened.
• That all moving parts move smoothly.
Fuel and oil
Recommended fuels
Use only a mixture of unleaded petrol and special
2-stroke engine oil. Mix the fuel mixture as indicated
in the fuel mixing table.
Important: Do not use a fuel mixture which has
been stored for longer than 90 days.
Important: Never use 2-stroke oil with a recom-
mended mixing ratio of 100:1. The manufacturer’s
warranty will be voided in case of engine damage
due to inadequate lubrication.
Important: Only use containers designed and ap-
proved for the purpose to transport and store fuel.
Pour the correct quantities of petrol and 2-stroke oil
into the mixing bottle (see scale printed on the bot-
tle). Then shake the bottle well.
Never use oil for 4-cycle engine or use water cooled
2-cycle engine. It can cause spark plug fouling ex-
haust part blocking or piston ring sticking.
Mixed fuels, which have been left unused for a pe-
riod of one month or more, may clog the carburetor
or result in the engine foiling to operate property. Put
remained fuel into an airtight container and keep it in
the dark and cool room.
Fuel mixing table
Mixing procedure: 40 parts petrol to 1 part oil
Example:
1 l Petrol : 0,025 l 2-stroke oil
5 l Petrol : 0,125 l 2-stroke oil
Warning!
Take care of the emission of exhaust gases.
Always shut o engine before fuelling. Never add
fuel to a machine with a running or hot engine.
Take care of re! Only ever refuel the tool out-
doors or in suciently ventilated rooms. Make
sure not to spill fuel or chain oil into the soil
(environmental protection). Use a proper base.
