Foreword Receivers
Here you will find the information which is needed to make your receiver perform at the very best. Both
the long range receivers and normal range receivers will be listed under each subject.
Physical and technical specifications
Rx700 Normal Range
The receiver board: 26 x 54mm.
Weight: 6.5 gr. (8.5 grams including wire)
Sensitivity: -102dBm.
Input supply voltage range: 4-10V.
Servo signal pulse output: 3.3V positive.
Radio band: 433 & 444 MHz multi band and multi frequency hopping system.
Temperature range: -40C to +70C tested.
Receiver 8ch - optimized input filter so it can co-exist with strong 2.4 GHz on board video transmitters.
Wire antenna mounted directly on the Rx.
The extra pin in ch 12 connector is RSSI out. Ch 12 connector is also PPM out when < 12ch are used.
PPM out is the same as sum-signal and this is of course fully compatible with MikroKopter controller board,
all RX have this SUM and RSSI out.
