29
LED indicators
The NR got one LED it simply indicates valid supply voltage.
The LR got two LED’s one located near each antenna connector.
The normal operation of the LED’s are during flight and installation to show what antenna signal is the
strongest, since that is the selected signal.
FAST Blinking LED during power up indicate search mode.
FAST Blinking LED during flight indicates failsafe is recalled and search mode is now running.
