Extension Board for MODBUS on SMARTCON Control Unit
DS-ENGLISH-MODBUS-V2.01-2019.05.15 4 Specification of Input and Output Data
4.2.7 Status 3
Register number: 263, address 0106
Hex
Data format: 16 bit, error codes
Error Code: Corresponds:
3 Motor temperature warning (only with ACTUSMART).
4 Motor temperature power-off.
5 Phase order error or phase failure.
9 Power supply error or frequency converter error.
11 Failsafe-Unit error (if available).
17 Travel sensor error.
22 Torque sensor error.
Using parameter P15.7 it is possible to assign alternative output-functions to ”Status 3”.
4.2.8 Status 4
Register number: 264, address 0107
Hex
Data format: 16 bit (Bitfield)
Structure:
Bitno.: Function: Description
0 and 1 Channel activity
Bit1 Bit0 Signal
0 0 Bus: Channel A active.
0 1 Bus: Channel B active.
1 0
Bus: Channel A and B active, main channel for
inputs is channel A.
1 1
Bus: Channel A and B active, main channel for
inputs is channel B.
2 reserved
3 reserved
4 reserved
5 reserved
6 reserved
7 reserved
8 and 9 PVST Status
Bit9 Bit8 Signal
0 0
PVST functionality not activated or no PVST
realised yet.
0 1 PVST active: There is a PVST active currently.
1 0 PVST OK: The last PVST was successful.
1 1 PVST Error: The last PVST was not successful.
10 reserved
11 reserved
12 reserved
13 reserved
14 reserved
15 reserved
Using parameter P15.8 it is possible to assign alternative output-functions to ”Status 4”.
