4 Specification of Input and Output Data
Extension Board for MODBUS on SMARTCON Control Unit
DS-ENGLISH-MODBUS-V2.01-2019.05.15
4.2.3 Actual torque value
Register number: 259, address 0102
Hex
Data format: 16 bit, only the lowest 8 bit (Bit 7: Direction OPEN; Bit 6 . . . 0: 0 . . . 100 corresponding to 0
. . . 100%) are in use.
Other bits are reserved for future use and have to be set to zero!
4.2.4 Actual speed value
Only with ACTUSMART!
Register number: 260, address 0103
Hex
Data format: 16 bit, only the lowest 8 bit (Bit 7: Direction OPEN; Bit 6 . . . 0: 0 . . . 100 corresponding to 0
. . . 100%) are in use.
Other bits are reserved for future use and have to be set to zero!
4.2.5 External actual value
Only with Option PID-Controller!
Register number: 261, address 0104
Hex
Data format: 16 bit, only the lowest 10 bits (0 . . . 1023) are in use.
Other bits are reserved for future use and have to be set to zero!
4.2.6 Status 2
Register number: 262, address 0105
Hex
Datenformat: 16 bit (Bitfield)
Structure:
Bitno.: Function: Description
Bit = 0 Bit 0 = 1
0 Dig. Output 1 - Corresponding binary output enabled.
1 Dig. Output 2 -
2 Dig. Output 3 -
3 Dig. Output 4 -
4 Dig. Output 5 -
5 Dig. Output 6 -
6 Dig. Output 7 -
7 Dig. Output 8 -
8 Dig. Input 1 - Corresponding binary input enabled.
9 Dig. Input 2 -
10 Dig. Input 3 -
11 Dig. Input 4 -
12 Dig. Input 5 -
13 PHASE SEQUENCE -
Phase Sequence Error: wrong phase order, phase failure,
total failure, asymmetry.
14 FC ERROR -
FC Error: Error in power supply or frequency converter (if
present).
15 FAILSAFE ERROR - Failsafe-Unit not ready (if present).
Using parameter P15.6 it is possible to assign alternative output-functions to ”Status 2”.
10
