Schiedel Prima Plus - Table of Contents; Approvals

2
Contents
Approvals
Prima Plus is CE Certified for the following applications:-
Connecting Flue Pipe - EN1856-2 TÜV 0036 CPR 9195 017
Chimney Liner - EN1856-2 TÜV 0036 CPR 9195 019
System Chimney - EN1856-1 TÜV 0036 CPR 9195 018
Approvals
Design guide
- Mandatory requirements
Prior to installation
- Ventilation
- Carbon monoxide alarms
- Handling
- Delivery to site and storage
Connecting ue pipe
- Appliance/chimney connection
- Connecting flue pipe diameter
- Distance to combustibles
- Connecting flue pipe route
- Inspection
Bs en 15287-1
- Acceptable alternative
- Methods of connection
Installation instructions
- Jointing system
- Standard connection flue pipe
sections
- Individual components
Chimney lining components
Offset dimensions
Page 2
Page 3
Page 4
Page 5-6
Page 7
Page 8-12
Page 13-17
Page 18
Page 19-20
Page 21
Page 21
Page 23
Page 23
Page 23
Typical installations
Max offset info
Component weightsAfter
installation
- Testing and commissioning prior
- Appliance operation
- Multi-fuel applications
- Maintenance
- Fuel storage and usage
Product guarantee
- Product registration
- Qr for installation assistant
Notice plate
Schiedel Installer Rewards
• *M stands for measured distance to combustibles on a connecting flue
pipe application in the range of diameters Ø150-Ø200
• For other diameters in the range the following distances should be used:
• When The product is used on solid fuel applications
• Ø100 = 375mm Ø130 = 390mm
** Used internally inside a non combustible shaft
*** Insulated and used internally inside a suitable enclosure
The Prima Plus range is manufactured under the strict requirements
of BS EN ISO 9001 Quality management scheme. Prima Plus has
corrosion certification from Gastec, MPA and TÜV. Prima Plus is
listed by HETAS as a product suitable for solid fuel. .
CE Designations are as follows:- High Temperature Applications Low Temperature Applications
Connecting Flue Pipe T600 N1 W V2 L50060 G400 M*
T200 P1 W V2 L50060 O200 M*
T200 N1 W V2 L50060 O200 M*
Chimney Liner T600 N1 W V2 L50060 G T200 P1 W V2 L50060 O
System Chimney
T450 N1 W V2 L50060 G50**
T450 N1 D V2 L50060 G50***
T200 P1 W V2 L50060 O200
