MAINTENANCE
30.30.01.00174/06 www.schmalz.com EN | 47
9.8 Vacuum filter for JumboFlex 20/35
9.8.1 Filter in the operator handle
An additional dust filter is built into the operator handle. It can be changed or cleaned
without the use of tools. Check, clean and, if necessary, replace the filter at
least once a month. The filter must be cleaned and maintained regularly to
guarantee that the tube lifter operates correctly.
Risk of injury from falling workpieces
If the filter screen in the suction pad is not cleaned regularly, the
negative pressure at the suction pad is reduced and the load will fall.
Clean the filter screen at least once per week in order to ensure the
safety of the device (see service table).
The operator handle filters can be replaced without tools.
