7
AZM201
Operating instructions
Solenoid interlock
EN
Table 1: Diagnostic information for the safety switchgear
The safety switch signals the switching condition as well as malfunctions via three coloured LEDs installed on the device.
System condition Solenoid control
IN
LED Safety outputs
Y1, Y2
Diagnostic
output OUT
Power to
unlock
Power to
lock
green red yellow AZM201Z AZM201B -1P2PW
Safety guard open 24 V (0 V) 0 V (24 V) On Off Off 0 V 0 V 0 V
Door closed, actuator not inserted 24 V 0 V On Off Off 0 V 0 V 0 V
Door closed, actuator inserted,
not locked
24 V 0 V On Off Flashes 0 V 24 V 24 V
Door closed, actuator inserted,
interlocking blocked
0 V 24 V On Off Flashes 0 V 24 V 0 V
Guard closed,
actuator inserted and locked
0 V 24 V On Off On 24 V 24 V 24 V
Error warning
1)
solenoid interlock locked 0 V 24 V On Flashes
2)
On 24 V
1)
24 V
1)
0 V
Error 0 V (24 V) 24 V (0 V) On Flashes
2)
Off 0 V 0 V 0 V
Additionally for variant I1/I2:
Teach-in procedure actuator started Off On Flashes 0 V 0 V 0 V
Only I2: teach-in procedure actuator
(release block)
Flashes Off Off 0 V 0 V 0 V
1) after 30 min: disabling due to fault
2) refer to flash code
Table 2: Error messages / flash codes red diagnostic LED
Flash codes
(red)
Designation Autonomous
switch-off after
Error cause
1 flash pulse Error (warning) at output Y1 30 min Fault in output test or voltage at output Y1,
although the output is disabled.
2 flash pulses Error (warning) at output Y2 30 min Fault in output test or voltage at output Y2,
although the output is disabled.
3 flash pulses Error (warning) cross-wire short 30 min Cross-wire short between the output cables or fault at both outputs
4 flash pulses Error (warning) temperature too
high
30 min The temperature measurement reveals an internal temperature
that is too high
5 flash pulses Actuator fault 0 min incorrect or defective actuator
6 flash pulses Error actuator combination 0 min An invalid combination of actuators was detected
(blocking bolt detection or tamper attempt).
Continuous red Internal fault /
overvoltage or undervoltage fault
0 min Device defective /
supply voltage not within specifications
