Accessories
The accessories required for mounting and operation of the SCHMIDT
®
Flow Sensor SS 20.600 are listed in Table 3 below.
Type / Art. no.
Drawing
Assembly
Connecting cable
Standard with
fixed length:
5 m 524921
- Threaded ring, knurl
- Plug injection-moulded
- Material:
Brass, nickel-plated
PUR, PVC
Connecting cable
Standard with
optional length:
x m 524942
- Threaded ring, knurl
- Material:
Brass, nickel-plated
Polyamide, PUR, PP
Halogen-free
11
Coupler socket
With thread
locking
524929
- Threaded ring, knurl
- Material:
Brass, nickel-plated
Polyamide, PUR, PP
- Connection of wires:
Screwed (0.25 mm
2
)
Clamp
12
a.) 524916
b.) 524882
- Internal thread G½, R½
- Material:
a.) Steel, black
b.) Stainless steel 1.4571
Table 3 Accessories
Informations about further accessories for mounting and display cis avail-
able on the SCHMIDT
®
homepage:
www.schmidt-sensors.com or www.schmidttechnology.de
11
According to IEC 60754
12
According to EN 10241; must be welded.
L=5m
14,5
5,1
42
L=XXm
20
54
5,9
54
20
für Kabel- 6-8 mm
26,6
34
Rp 1/2
Cable Ø:
4 … 6 mm
