KL 1500 compact – Instructions for Use
3/12
Instrument overview
(1) Power switch 2.2
(2) Light guide connection 2.1
(3) Fixing screw 2.1
(4) Electronic light intensity setting 2.3
(5) Filter slide 2.4
(6) Carrying handle
(7) Lamp compartment with halogen cold light reflector lamp 3.
(8) Mains cable connection
(9) Ventilation openings (base of instrument) 1.
(10) Air outlet grid (back of instrument) 1.
(11) Model plate (base of instrument)
1 2 3
4 5
6
7
8
9
10
11
