KL 1500 compact – Instructions for Use
6/12
2. Operation
2.1 Light guide connection
First undo the fixing screw (3) of the light guide socket (2) by turning in an anti-clockwise direction.
Push the light guide in as far as the stop and tighten the fixing screw by turning clockwise.
Caution: When inserting light guides with a location pin, care must be taken to ensure the pin fits
into one of the two guide slots.
2.2 Start-up procedure
Switch on/off by operating the power switch (1) .
Position O visible: The instrument is switched off and in stand-by condition. For disconnection
from the power supply, please pull out the mains plug!
To protect the halogen lamp the KL 1500 compact is fitted with a gentle start-up device that
reduces the high switch-on current that would otherwise occur.
In addition, electronic stabilisation of the lamp voltage ensures stable light power regardless of
fluctuations in the mains voltage.
