KL 1500 compact – Instructions for Use
12/12
Lighting information
Maximum effective light guide
bundle diameter mm 9
Total light flux at light guide exit
(SCHOTT light guide, Ø 9 mm, typical values)
Level 4 lm
Level 5 lm
250
450
Light entry angle (2α
eff
)
approx. 53°
Heat protection filter - SCHOTT KG 2, 45 x 45
thickness = 2,0 mm,
toughened
Approvals -
EMV-class -
CE, CSA
A
The right is reserved to make changes in the design and supplied items within the scope of on-
going technical development.
Warning! This is a EMV class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate measures. In this
case, please contact the cusomer service.
SCHOTT AG
Business Unit Fiber Optics
Otto-Schott-Straße 2
55127 Mainz
Tel. 0049 / (0)6131 / 66 - 0
