3. ANATOMY OF THE HELMET
4. OUTER SHELL
The outer shell of the R2 helmet combines an aerodynamically optimal shape
with consistent protection. It consists of a special glass-bre reinforced special
duroplastic matrix developed by SCHUBERTH, which gives the helmet the high
level of strength needed for your protection.
Caution:
The safety helmet is designed to absorb the eects of only one impact.
The helmet must be replaced after a fall, accident or any other impact.
5. INNER SHELL
For optimised impact absorption properties, the inner shell of the helmet
consists of several components. The complex multi-segment foam padding of
the main body provides better absorption and dissipation of impact forces and
gives you the highest level of safety.
Face shield
Inner lining
Face shield
ventilation/
Chin ventilation
Integrated
antennas
Head ventilation
Inner shell
Visor mechanicsk
Outer shell
Chinstrap
(with double-D-
fastening)
Head outlet vent
Anti-fog lens
Chin bar release
