EN
55
FITTING INNER LINING
Installing head padding
Using the red pins, attach the head padding to
the two connectors in the forehead area and
the one at the back of the helmet
Fitting the high-comfort cheek pads
1. Pull the chinstrap through the cheek
pads on each inner side.
