4 01.00 | IN / INK | Assembly and Operating Manual | en | 1596635
1 General
1.1 About this manual
This manual contains important information for a safe and
appropriate use of the product.
This manual is an integral part of the product and must be kept
accessible for the personnel at all times.
Before starting work, the personnel must have read and
understood this operating manual. Prerequisite for safe working
is the observance of all safety instructions in this manual.
1.1.1 Presentation of Warning Labels
To make risks clear, the following signal words and symbols are
used for safety notes.
CAUTION
Material damage!
Information about avoiding material damage.
1.1.2 Applicable documents
l
General terms of business *
l
Catalog data sheet of the purchased product *
l
Assembly‐ and Operating Manual of the SCHUNK-module, on
which the sensor is mounted *
The documents labeled with an asterisk (*) can be downloaded
from schunk.com/downloads.
1.1.3 Sizes
This operating manual applies to the following sizes:
l
IN / INK 5
l
IN / INK 8
l
IN / INK 30
l
IN / INK 40
l
IN / INK 41
l
IN / INK 50
l
IN / INK 60
l
IN / INK 65
l
IN / INK 80
