Troubleshooting
01.00 | IN / INK | Assembly and Operating Manual | en | 1596635 13
5 Troubleshooting
5.1 Sensor not operating
Possible cause Corrective action
l
No control cam available
l
Cable breakage
l
No voltage or voltage too
low
Check whether the control cam is present.
Check whether the sensor cable is broken.
Check whether the voltage at the sensor is between 10 -
30VDC.
Remove the sensor from the module, see the Assembly and
Operating Manual for the module.
Connect the sensor to the power supply.
Version with LED
Touch a level metal surface with the front of the sensor and
check whether the LED lights up on the sensor.
Version without LED
Touch a level metal surface with the front of the sensor and
check whether voltage is present at the sensor output (pin4).
Install the sensor on the module, see the Assembly and
Operating Manual for the module.
Version with LED
Check whether the LED lights up at the position to be sensed
and that the sensor is operating.
NOTE
If the LED does not light up or the sensor is not operating,
contact SCHUNK Service.
5.2 Sensor is operating, but not as desired
Possible cause Sources of interference Corrective action
The sensor is interfered with or
influenced by external
magnetic or soft magnetic
materials (Fe).
Motors (coils) Increase the distance
between the sensor and the
mentioned sources of
interference (until the
sensor switches correctly).
Relays
Linear motors
Electrical welding
Magnetized components and
workpieces (workpieces made
of iron or similar materials)
Use finger attachments
made of aluminum.
Magnetized components and
tools (adapter plates made of
iron, iron screws or iron
hexagon socket keys, etc.)
Use components containing
aluminum. For example,
V4A screws are
recommended.
