Assembly and settings
01.00 | MMS 22-IOL | Assembly and Operating Manual | en | 1598377 9
5 Assembly and settings
5.1 Mechanical connection
NOTE
The assembly instructions in this chapter are generally
applicable.
Module-specific assembly instructions for the sensor can be
found in the Assembly and Operating Manual for the module,
which can be downloaded at schunk.com
CAUTION
Material damage due to an incorrect tightening torque!
If the threaded pin is tightened with an incorrect tightening
torque, the product may be damaged.
l
Observe a maximum tightening torque of 10 Ncm for the set-
screws.
5.2 Electrical connection
CAUTION
Material damage due to incorrect bending radii!
The product may get damaged if the bending radius of the cable
is less than the minimum.
l
See catalog datasheet for corresponding details.
NOTE
l
Do not use the sensor as a safety component.
l
Do not pull on the cable of the sensor.
l
Secure the cable and connector so that they are not taught
and cannot move during operation.
l
Do not exceed the permitted bending radius of the cable.
l
Do not allow the sensor to come into contact with hard
objects or chemicals (e.g. nitric, chromic and sulfuric acid)
Ferromagnetic components change the magnetic field and the
function of the sensor, e.g. adapter plate made of construction
steel. For ferromagnetic adapter plates:
l
First, install the module on the adapter plate.
l
Then teach in sensor.
The sensor is an electronic component that can be sensitive to
high-frequency interference or electromagnetic fields.
