Schwing Rock Valve - Hopper Area

Overview
All SP Rock Valve Models
Startup 250:Users:Danny:Desktop:Operation
manuals:line pumps:All SP Rock Valve models:Frame
Operation Manual -
63
Hopper Area
• Agitator motor (Figure 16) is a hydraulically
driven motor that is directly coupled to the
agitator shaft.
SWG98n164.eps
Agitator
motor
Grease bar
Tension nut
Clean-out door
Outlet pipe
Grease zerk
Tension nut
locking bolt
Vibrator
Hopper grate
interlock switch
Figure 15
Components of the Hopper Area
Figure 16
Agitator Motor
