Again, plot the results on a clean copy of the owchart.
As we plot this pump, we can see that the dots are mov-
ing quite a bit to the inside of the ow specication (see
below).
When you connect the dots, the line is completely be-
low the specications. This pump is very weak and will
completely stop pumping oil soon. You may notice high
heat with this unit if you are pumping at high oil pres-
sures.
Never try to make up for this weak pump by in-
creasing the speed of the engine. If the pump
turns faster than specication, it will not be able
to draw oil as fast as it is turning (“cavitation”),
and immediate failure could result.
If the plotted curve matches the specication plot for a
while but the breakpoint is too high or too low, it is possi-
ble to make an adjustment. Contact Schwing America’s
Service Center for the procedure.
There are many di󰀨erent possible pump kits and pow-
er settings for this unit. If you accidentally destroy your
original output chart, please have your serial number
handy when you call to get a replacement. Also, please
advise us if you have changed di󰀨erential cylinders,
material cylinders, or hydraulic pumps, because you
may need a di󰀨erent output chart than the one that was
originally shipped with the unit.
