Specications
SP 750-15 / 750-18 / 1000 / 1250 Operation Manual
SP 750-15
Concrete Pumpkit 80/50 x 1000:150
Concrete Valve Long Rock
Maximum Strokes/minute 35
Maximum Concrete Volume 50 cu. yd
3
/hr 38 cu. m
3
/hr
C4.4 Tier 3 - Diesel Motor 100 hp 75 Kw
C3.4 Tier 4 - Diesel Motor 100 hp 75 Kw
Electric Motor 100 hp 75 Kw
Output - Hydraulic Pumps 65 gpm 240 L/min
Hydraulic Pumps RPM- Diesel 2200 rpm
Hydraulic Pumps RPM- Electric 1800 rpm
Maximum Hydraulic Pressure 3872 psi 267 bar
Maximum Pressure on Concrete 1100 psi 75.8 bar
Maximum Aggregate Size 1.5” 38.1 mm
Pumping Cylinder Diameter 6” 152.4 mm
Stroke Length 39“ 990.6 mm
Di󰀨erential Cylinder Diameter 3” 80 mm
Charging Hopper Height 51” 1292 mm
Fuel Tank Capacity 40 gal. 150 L
Hydraulic Tank Capacity 112 gal. 424 L
Gross Weight N/A N/A
Length 197” 4997 mm
Width 76” 1929 mm
Height (Tier 3) 96” 2438 mm
Height (Tier 4) 102” 2590 mm
Remote Control Cable Length 100’ 30.5 m
* Max RPM of the hydraulic pumps is calculated while the pump is under a full load. Depending on the unit it is ac-
ceptable for the max RPM to vary slightly from the published estimate.
