21
Specications
SP 750-15 / 750-18 / 1000 / 1250 Operation Manual
SP 1000HP
Concrete Pumpkit 90/50 x 1000:150
Concrete Valve HP Short Rock Valve
Maximum Strokes/minute 26
Maximum Concrete Volume 35 cu. yd
3
/hr 26.7 cu. m
3
/hr
Diesel Motor (C4.4 Tier 3) 139 hp 104 Kw
Diesel Motor (C4.4 Tier 4) 137 hp 102 Kw
Electric Motor 125 hp 93 Kw
Output - Hydraulic Pumps 65 gpm 240 L/min
Hydraulic Pumps RPM- Diesel 2200 rpm
Hydraulic Pumps RPM- Electric 1800 rpm
Maximum Hydraulic Pressure 4032 psi 278 bar
Maximum Pressure on Concrete 1450 psi 100 bar
Maximum Aggregate Size 0.5” 152 mm
Pumping Cylinder Diameter 6” 152.4 mm
Stroke Length 39“ 990.6 mm
Di󰀨erential Cylinder Diameter 3.5” 90 mm
Charging Hopper Height 51” 1292 mm
Fuel Tank Capacity 40 gal. 150 L
Hydraulic Tank Capacity 105 gal. 400 L
Gross Weight 9125 lbs. 40.5 kN
Length 200” 4840mm
Width 76” 1835 mm
Height (Tier 3) 96” 2440 mm
Height (Tier 4) 94” 2400 mm
Remote Control Cable Length 100’ 30.5 m
