Schwinn 810 - Treadmill Assembly

11
Tools
Included
Item Qty Description Item Qty Description
A 8 ButtonHeadHexScrew,M8x1.25x85 E 4 ButtonHeadHexScrew,M8x1.25x16
B 10 Flat Washer, M8 F 2 SelfTappingScrew,M3.9x13
C 12 Lock Washer, M8 G 6 PhillipsHeadScrew,M4x0.7x12
D 2 Curved Washers, M8
Note: Select pieces of Hardware have been provided as spares on the Hardware Card. Be aware that there may
be remaining Hardware after the proper assembly of your machine.
HARDWARE / TOOLS
#2
6 mm
6 mm
A B D
C E F G
ASSEMBLY
DO NOT CUT the Shipping Strap on the Base Assembly until it has been placed face up as
shown in the appropriate work space.
