Page 7
Shroud Removal
REPLACEMENT PROCEDURES
1. Use a #2 phillips screwdriver to remove the screw securing
the right side ywheel cap to the bike, then remove the
cap.
2. Use a #2 phillips screwdriver to remove the screws securing
the left generator cover to the bike
3. With the left generator cover removed, use a screwdriver to
remove the screw hidden by the generator board, angled
as shown.
4. Use a #2 phillips screwdriver to remove the screws securing
the outer chainguard to the bike
