6
SPECIFICATIONS
Before Assembly
Select the area where you are going to set up and operate your
machine. For safe operation, the location must be on a hard, level
surface.Allowaworkoutareaofaminimum3.5mx1.8m(138”x69”).
Basic Assembly Tips
Follow these basic points when you assemble your machine:
• Readandunderstandthe“ImportantSafetyInstructions”before
assembly.
• Collect all the pieces necessary for each assembly step.
• Using the recommended wrenches, turn the bolts and nuts to the
right(clockwise)totighten,andtheleft(counterclockwise)toloosen,
unless instructed otherwise.
• When attaching 2 pieces, carefully lift and look through the bolt holes
to help insert the bolt through the holes.
• The assembly requires 2 people.
Maximum User Weight: 136kg(300lbs.)
Machine Weight:  40.8kg(90lbs.)
Dimensions (at):  226.3cmx53.5cmx80.5cm(89.1”x21.1”x31.7”)
Total Surface Area (footprint) of equipment: 12,107 cm
2
Dimensions (folded):  129.5cmx53.5cmx144.8cm(51”x21.1”x57”)
Power Requirements: 2AAAlkalineBatteries(UN-3)
Operating Voltage: 3VDC
Specications
DO NOT dispose of this product as refuse. This product is to be recycled. For proper disposal of this product,
please follow the prescribed methods at an approved waste center.
0.6m
24”
0.6m
24”
0.6m
24”
0.6m
24”
3.5m
138”
1.8m
69”
