This product is intended for indoor use at altitudes up to 2000 meters, Pollution Degree 1 or 2 in accordance with IEC 664 and transient overvoltages according to Installation
Categories (Overvoltage Categories) I, II and III. For mains supply, the minimum and normal category is II.
SPECIFICATIONS SA SERIES ANALYTICAL BALANCES
Model SA 80 SA 120 SA 210 SA 310 SA 410 SA 510 SA 210D SA 525D
Weighing Mode Single Range Dual Range
(Floating Tare™)
Capacity 80g 120g 210g 310g 410g 510g 100g 250g
200g 500g
Readability .0001g .0001g
.001g
Tare Range 0-80g 0-120g 0-210g 0-310g 0-410g 0-510g 0-200g 0-500g
0-200g 0-500g
Repeatability .0001g .0001g .0001g .00015g .00015g .0002g .0001g .00015g
(Standard
Deviation)
.0005g .0005g
Linearity ±.0002g ±.0002g
±.0005g
Stabilization Time User Selectable
Weighing Speed Adaptive
Display Update
Interval
200ms
Data Interface RS-232 bidirectional interface is standard. Baud rates are 300, 600, 1200, 2400, 4800, 9600 and
19,200.
Pan Size Circular 3.5 inch diameter
Operating
Temperature
5°C to 40°C
Relative Humidity 80 % for temperatures up to 31°C decreasing linearly to 50 % at 40°C
Power Supply 115 Volts/60 Hz ± 10 %
230 Volts/50Hz or 60 Hz ± 10 %
Windscreen 7.5W x 8.25D x 9.5H
Calibration Weight 80g 100g 200g 300g 400g 500g 200g 500g
50g 50g 100g 200g 200g 100g 200g
Housing (WxDxH) 7.5" x 11.25" x 3.25"
Weight ~ 13.8 lbs
