Step 1:Place one hand on the back
of the seat cushion back support.
Step 2 Option #1 (Adjustable Only):
Use the other hand to pull upward and hold the
yellow T-Handle located in front of the seat.
Step 2 Option #2 (Adjustable or Fixed/Swivel)
Step on the yellow foot pedal
Step 3: Slide the seat assembly forward or backwards on the
machine seat track to the desired position.
SCIFIT Scientic Solutions For Fitness SCIFIT Scientic Solutions For Fitness SCIFIT
Step 1:Place one hand on the back
of the seat cushion back support.
Step 2a (Adjustable Only): Use the other hand to pull upward
and hold the yellow T-Handle located in front of the seat.
Step 2b (Fixed/Swivel): Step on the yellow foot pedal.
Step 3: Slide the seat assembly backwards until it is
completely off of the machine seat track.
SPECIFICATIONS
The seat can be adjusted in 25.4mm increments and is held
in place with a spring loaded pin. This is done by using one
of two options (1) Pull cable or (2) Foot pedal.
