scope R4C - Replacing Front Wheel Bearings

To Next Page

To Previous Page

FRONT

WHEEL

REPLACING THE BEARINGS

To replace the bearings you’ll need the following tools:

• BearingInstallationTool(T1/T2/T3)

• LongBearingPresshead(T4)

• ShortBearingPresshead(T5)

• 15mmGuide(T9)

Apply a small amount of grease on both

bearing seats of the hub.

Carefullyplaceonebearing(2)inthebearing

seat without applying pressure.

Placethelong1524/1528(T5)pressheadand

15mmguide(T9)onthebearingremovaltool

(T1&T2)withthe1524sidefacingthehub.

Slide the tool into the hub and place the short

1524/1528(T5)pressheadontheoppositeside,

thenscrewonthehandle(T3).
