REPLACING THE BEARINGS
To replace the bearings you’ll need the following tools:
• Bearingremovaltool(T1/T2/T3)
• Longpresshead1524/1528(T4)
• Shortpresshead(1524/1528(T5)
• 15mmguide(T9)
Apply a small amount of grease onto both
bearing seats of the hub.
Carefullyplaceonebearing(2)onthebearing
seat on the drive-side without applying pressure.
Placethelong1524/1528(T5)pressheadand
the15mmguide(T9)onthebearingremoval
tool(T1&T2)withthe1524sidefacingthehub.
Slide the tool into the hub and place the short
1524/1528(T5)pressheadontheoppositeside,
thenscrewonthehandle(T3).
1
2
3
4
