REAR
WHEEL
Inserttheaxleintothehub(11).
Carefullyplacetheotherbearing(13)inthe
bearing seat on the non-drive side without
applying pressure.
Gently tighten the bearing removal tool and
assure its correct position on the bearing.
Tighten the bearing removal tool until the
bearing is fully seated.
Check the alignment to make sure the bearings
run smoothly.
Repeat steps 3-7 but do not use the 15mm
guide(T9).
Placethefreehubspacer(7)onaxledriveside.
Placethelong1524/1528(T5)pressheadand
the15mmguide(T9)onthebearingremoval
tool(T1&T2)withthe1524sidefacingthehub.
8
9
5
6
7
10
11
12
