scope R4C - Removing Rear Wheel Bearings

15
REAR
WHEEL
REMOVING THE BEARINGS
To remove the bearings you’ll need the following tools:
• BearingRemovalTool(T1/T2/T3)
• 1xPlasticPresshead(T6)
• LargeSpacer(T9)
• SmallSpacer(T8)
Remove the freehub and hub cap from the
hubbypullingitofftheaxle.
Removethefreehubspacerfromtheaxle.
Pull off the non-drive side hub cap by hand.
Placeasmallthreadedplasticpresshead(T6)
onthebearingremovaltool(T1&T2)andinsert
thetoolintotheaxlefromthedrivesideofthe
hub.
Placethesmallspacer(T8)onoppositeside
of the hub and screw on the bearing removal
toolhandle(T3).
Gently tighten until the bearing is released.
Takethehubaxle(11)turnitaroundandplace
it into the non-drive side of the hub.
1
2
3
4
5
6
7
